Walt's Tractor Parts | John Deere Tractor Parts -- | John Deere Power Take Off Parts - |  PTO Shafts -

PTO Shafts -

UJD60151 PTO Shaft---Replaces AT20094

UJD60151 PTO Shaft---Replaces AT20094
Replaces number AT20094

6.875" long---6 spline---540 RPM

Fits: 820, 920, 1020, 1030, 1120, 1130, 1520, 2020, 2030, 2120, 2440, 300, 301, 302, 400, 401

Price: $250.00

UJD60152 PTO Shaft---Replaces AT29707

UJD60152 PTO Shaft---Replaces AT29707
Replaces number AT29707, JDS4081

9.203" long---6 spline---540 RPM

Does Not Include Bearing Race

Fits: 840, 940, 1020, 1030, 1040, 1120, 1130, 1140, 1350, 1520, 1550, 1640, 1830, 1840, 1850N, 1950, 1950N, 2020, 2030, 2040, 2040S, 2120, 2130, 2140, 2250, 2355N, 2440, 2450, 2550, 2555, 2630, 2640, 2650, 2650N, 2750, 2755, 2850, 2855N, 300, 301, 400, 401

Price: $160.00

UJD60153 PTO Shaft---Replaces T30803

UJD60153 PTO Shaft---Replaces T30803
Replaces number T30803

9.781" long---21 spline---1000 RPM

Fits: 840, 940, 1020, 1030, 1040, 1120, 1130, 1140, 1350, 1520, 1550, 1640
1830, 1840, 1850N, 1950, 1950N, 2020, 2030, 2040, 2040S, 2120, 2130, 2140
2440, 2250, 2450, 2650, 2850, 2855N, 300, 301, 400, 401

Price: $240.00

UJD60154 PTO Shaft---Replaces AT20095

UJD60154 PTO Shaft---Replaces AT20095
Replaces number AT20095

5.29" long---21 spline---1000 RPM

Fits: 820, 920, 1020, 1030, 1120, 1130, 1520, 2020, 2030, 2120, 2440 SN<340999, 300, 301, 302, 400, 401

Price: $190.00

UJD60155 PTO Shaft---Replaces AR41753

UJD60155 PTO Shaft---Replaces AR41753
Replaces number AR41753

10.687" long---1.1820" Bearing surface---6 spline---540 RPM

Fits: 2510, (3020 before s.n. 122999), (4020 before s.n. 200999), 500, 500A, 600

NOTE: if end of shaft is 1.5625 you will need to order UJDJD7557 press bushing

Price: $145.00

UJD60172 Internal PTO Shaft---Replaces R32609

UJD60172 Internal PTO Shaft---Replaces R32609
Replaces number R32609

Fits: 4010

Price: $1,050.00

UJD60156 PTO Shaft---Replaces AR41752

UJD60156 PTO Shaft---Replaces AR41752
Replaces number AR41752, R38223

10.687" long---1.1815" Bearing Surface---6 spline,540 RPM.

Fits: 2510, 2520, 2840, (3020 after s.n. 123000), 4000, (4020 after s.n. 201000), 4320, 4030, 4230, 4430, 4040, 4240, 4440, 4050, 4250, 4450, 4055, 4255, 4455, 500A, 500B, 500C

NOTE: if end of shaft is 1.5625 you need to order UJDJD7557 press bushing

Price: $112.00

UJDJD7557 PTO Conversion Bushing---Replaces JD7557

UJDJD7557 PTO Conversion Bushing---Replaces JD7557
Replaces number JD7557, JD10283

Fits: 1020, 1120, 1520, 2020, 2030, 2120, 2140, 2355, 2355N, 2440, 2510 (SN 010491>), 2520, 2550, 2555, 2630, 2640, 2750, 2755, 2840, 2855N, 2940, 2950, 2955, 3020 (SN 102697>), 3040, 3055, 3140, 3150, 3155, 3255
4000, 4020 (SN 154230>), 4030, 4040, 4050, 4055, 4230, 4240, 4250, 4255, 4320, 4430, 4440, 4450, 4455

Fits: Industrial: 300, 301, 400, 401, 500, 500A, 500B, 500C, 600

Price: $13.00

UJD60157 PTO Shaft---Replaces R41756

UJD60157 PTO Shaft---Replaces R41756
Replaces number R41756

10.687" long---6 spline---540 RPM

Fits: 2840, 2940, 2950, 2955, 3030, 3040, 3050, 3055, 3120, 3130, 3140, 3150, 3155, 3255, 3350, 3650, 4055, 4255, 4350, 4555

Price: $112.00

UJD60158 PTO Shaft---Replaces T28672

UJD60158 PTO Shaft---Replaces T28672
Replaces number T28672

11.414" long,---21 spline---1000 RPM

Fits: 2840, 2940, 2950, 2955, 3030, 3040, 3050, 3055, 3120 3130, 3140, 3150, 3155, 3155, 3255, 3350, 3650, 4350
.

Price: $180.00

UJD60159 PTO Shaft---Replaces L39949

UJD60159 PTO Shaft---Replaces L39949
Replaces number L39949

40" long---6 spline---540 RPM

THIS IS THE HEAVY DUTY SHAFT THAT USES TIMKEN TYPE BRGS. NOT BALL BEARING TYPE

Fits: 840, 940, 1040, 1140, 1350, 1550, 1640, 1750, 1840, 1850, 1950, 1950N, 2040, 2040S, 2140, 2150, 2155, 2250, 2255, 2350, 2355, 2355N, 2450, 2550, 2555, 2650, 2650N, 2750, 2755, 2850, 2855N

Price: $495.00

UJD60160 PTO Shaft---Replaces AT23224

UJD60160 PTO Shaft---Replaces AT23224
Replaces number AT23224, T22542

21/21 spline---11.340" Long

Fits: 820, 830, 920, 930, 1020, 1030, 1120, 1130, 1520, 1530, 1630, 1830, 2020, 2030, 2040, 2120, 2130
2150, 2155, 2240, 2255, 2350, 2355, 2355N, 2440, 2550, 2555, 300, 300B, 301, 301A, 302, 302A, 400, 401, 401B, 401C, 401D

Price: $250.00

UJD60161 PTO Shaft---Replaces L38806

UJD60161 PTO Shaft---Replaces L38806
Replaces number L38806

31.25" long---6 spline---540 RPM.

Fits: 1030, 1130, 1350, 1550, 1630, 1640, 1641F, 1750, 1850, 2030, (2040, 2240 after s.n. 350000), 2130, 2140, 2150, 2155, 2250, 2255, 2350, 2355, 2450, 2550, 2750, 2555, 2750, 2755, 2855
(820, 920, 1020, 1120 for models with heavy duty PTO bearings)
(840, 940, 1040, 1140, all sn 437370>)

Price: $375.00

UJD60162 PTO Shaft---Replaces AR28572

UJD60162 PTO Shaft---Replaces AR28572
Replaces number AR28572

5.31" long---6 spline---540 RPM

Fits: 3010, 4010 .

Price: $105.00

UJD60163 PTO Shaft---Replaces AR28573

UJD60163 PTO Shaft---Replaces AR28573
Replaces number AR28573

4.275" long---21 spline---1000 RPM

Fits: 3010, 4010

Price: $115.00

UJD60164 PTO Shaft---Replaces R38224SP

UJD60164 PTO Shaft---Replaces R38224SP
Replaces number R38224SP

10.875" long---6 spline---540 RPM

Fits: 2510, 2520, 2840, (3020 after s.n. 123000), 4000, (4020 after s.n. 201000), 4320, 4030, 4230, 4430, 4040, 4240, 4440, 4050, 4250, 4450, 4055, 4255, 4455

Industrial 500A, 500B, 500C, 600

Price: $180.00

UJD60165 PTO Shaft---Replaces R38224

UJD60165 PTO Shaft---Replaces R38224
Replaces number R38224

10.875" long---21 spline---1000 RPM

Fits: Fits: 2510, 2520, 2840, (3020 after s.n. 123000), 4000, (4020 after s.n. 201000), 4320, 4030, 4230, 4430, 4040, 4240, 4440, 4050, 4250, 4450, 4055, 4255, 4455

Industrial 500A, 500B, 500C, 600

Price: $130.00

UJD60166 PTO Shaft---Replaces R33342

UJD60166 PTO Shaft---Replaces R33342
Replaces number R33342

10.875" long---21 spline---1000 RPM

Fits: 2510, (3020 before s.n. 122999), (4020 before s.n. 20099)

Price: $170.00

UJD60167 PTO Shaft---Replaces R43531

UJD60167 PTO Shaft---Replaces R43531
Replaces number R43531

60.00" long---1000 RPM---21/21 Spline

Fits: 4520 Synchro-Range

Price: $400.00

UJD60168 PTO Shaft---Replaces R47642

UJD60168 PTO Shaft---Replaces R47642
Replaces number R47642

55.250" long---1000 RPM---21/27 Spline

Fits: 4620 Power Shift

Price: $595.00

UJD60169 PTO Shaft---Replaces R50300

UJD60169 PTO Shaft---Replaces R50300
Replaces number R50300

54.812" long---1000 RPM---21/ 6 Splines Spline

Fits: 4630 Power Shift

Price: $955.00

UJD60170 PTO Shaft---Replaces R51100

UJD60170 PTO Shaft---Replaces R51100
Replaces number R51100

54.187" long---1000 RPM---21/ 6 Splines

Fits: 4630 Synchro Range sn <6999

Price: $775.00

UJD60173 PTO Shaft---Replaces R54545

UJD60173 PTO Shaft---Replaces R54545
Replaces number R54545

62.375" long---1000 RPM---21/ 26 Spline

Fits: 4630 Quad/Synchro Range sn 7000 >

Price: $785.00

UJD60174 PTO Shaft---Replaces R59063

UJD60174 PTO Shaft---Replaces R59063
Replaces number R59063

60.375" long---1000 RPM---20/ 26 Spline

Fits: 4640 Quad Range

Price: $880.00

UJD60175 PTO Shaft---Replaces R72447

UJD60175 PTO Shaft---Replaces R72447
Replaces number R72447, R58001

52.531" long---1000 RPM---20/ 6 Spline

Fits: 4640 and 4840 Power Shift

Price: $580.00

UJD60177 PTO Shaft---Replaces R80884

UJD60177 PTO Shaft---Replaces R80884
Replaces number R80884, R77767

For Power Shift Transmissions

56.500" long---1000 RPM---20/ 28 Spline

Fits: 4555, 4560, 4650, 4755, 4760, 4850, 4955, 4960

Price: $800.00

UJD60178 PTO Shaft---Replaces R80881

UJD60178 PTO Shaft---Replaces R80881
Replaces number R80881, R77766

For MFWD with Power Shift

59.937" long---1000 RPM---20/ 28 Spline

Fits: 4555, 4560, 4650, 4755, 4760, 4850, 4955, 4960

Price: $730.00

UJD60179 PTO Shaft---Replaces R80883

UJD60179 PTO Shaft---Replaces R80883
Replaces number R80883, R72877

For Quad Range Transmissions with Digital Tach Pickup

60.312" long---1000 RPM---20/ 26 Spline

Fits: 4555, 4560, 4650, 4755, 4760, 4850, 4955, 4960

Price: $900.00

UJD60180 PTO Shaft---Replaces R113859

UJD60180 PTO Shaft---Replaces R113859
Replaces number R113859

10.96" long---540 RPM---6/ 21 Spline

Fits: 5200, 5210, 5220, 5300, 5310, 5320, 5400, 5410, 5415, 5420, 5500, 5510, 5520, 5615, 5715

Price: $115.00

UJD60181 PTO Shaft---Replaces R266970

UJD60181 PTO Shaft---Replaces R266970
Replaces number R266970, R122910, R561721

1.750" Diameter---1000 RPM

Fits: TRACTOR: 7630, 7730, 7820, 7830, 7920, 7930, 8100, 8110, 8120
8130, 8200, 8210, 8220, 8225R, 8230, 8235R, 8245R, 8260R, 8270R, 8285R

Price: $220.00

UJD60182 PTO Shaft---Replaces L76496

UJD60182 PTO Shaft---Replaces L76496
Replaces number L76496

14.11" long---540 RPM---25/6 Spline

Fits: 6110, 6110L, 6120, 6120L, 6200, 6200L, 6210, 6210L, 6220
6220L, 6300, 6300L, 6310, 6310L, 6310S, 6320, 6320L, 6405, 6420

Price: $260.00

UJD60183 PTO Shaft---Replaces L155266

UJD60183 PTO Shaft---Replaces L155266
Replaces number L155266, L150201, L155266

9.26" long---540/1000 RPM---21/14/6 Spline

Fits: 6120, 6120L, 6215, 6220, 6220L, 6320, 6320L, 6415, 6420, 6420L, 6520L, 6615, 6715

Price: $165.00

UJD60184 PTO Shaft---Replaces R110061

UJD60184 PTO Shaft---Replaces R110061
Replaces number R110061

39" long---1000 RPM---20 Spline

Fits: 8100, 8100T, 8110, 8110T, 8120, 8120T, 8200, 8200T, 8210, 8210T, 8220, 8220T, 8300, 8300T, 8310, 8310T, 8320, 8320T, 8400, 8400T, 8410, 8410T, 8420, 8420T, 8520, 8520T

Price: $380.00

UJD60185 PTO Shaft---Replaces R122910

UJD60185 PTO Shaft---Replaces R122910
Replaces number R122910, R266970, R561721

9.60" long---1000 RPM---20/33 Spline

Fits: 8100, 8110, 8120, 8200, 8200T, 8210, 8220, 8300, 8310, 8320, 8400, 8410, 8420, 8520

Price: $230.00

UJD60186 PTO Shaft---Replaces R122909

UJD60186 PTO Shaft---Replaces R122909
Replaces number R122909, L110178, L151598, R125087, R161794

Dim A (1)--- 13.47" Long
Dim B (2)--- 21/6/29 Spline

Fits: 8100, 8110, 8120, 8200, 8200T, 8210, 8220, 8300, 8310, 8320, 8400, 8410, 8420, 8520

Price: $330.00

UJD60187 PTO Shaft---Replaces L156976

UJD60187 PTO Shaft---Replaces L156976
Replaces number L156976, L110178, L151598, R125087, R1611794, R93500, SMATIS

540/1000---9.20" Long---6/21 Reversible

Fits: 6110,, 6110L, 6200, 6200L, 6210, 6210L, 6300, 6300L, 6310, 6310L, 6310S, 6400, 6400L, 6403, 6405, 6410, 6410L, 6410S, 6500, 6510L, 6510S, 6603, 6605, 7200, 7210, 7400, 7405, 7410, 7420, 7500, 7510, 7520, 7600, 7610, 7700, 7710, 7800, 7810

Price: $140.00

UJD60188 PTO Shaft---Replaces L113338

UJD60188 PTO Shaft---Replaces L113338
Replaces number L113338

540/1000---9.20" Long---6/21 Reversible

Fits: 6200, 6200L, 6300, 6300L, 6400, 6400L, 6500L

All Models Serial Number 153106-166897

Price: $225.00
